Packaging information
CTN Szie: 40 × 30 × 30 cm
G.W./CTN:9 kg
QTY/CTN:48 set/carton
Product Features | ||||
1. Precise positioning with an accuracy of 5 meters 2.gps + Beidou + LBS three-model positioning 3. Three-proof design: waterproof, dustproof and drop-proof. 4. Full functions include ACC detection, remote oil and electricity cut-off (optional), power failure alarm, overspeed alarm, vibration alarm, displacement alarm, ACC illegal start alarm, etc. 5. Wide voltage design support 9v-75v | ||||
application areas | ||||
rental vehicles, credit vehicles, passenger vehicles, taxis, freight vehicles, etc. | ||||
Device parameters | ||||
project | the feature name | there are | no | functional description |
electrical characteristics | power supply | ● |
| battery power supply |
operating voltage range | ● |
| DC 9V - 75V | |
working current | ● |
| 12V/30MA - 60MA | |
sleep current | ● |
| 12V/5MA - 15MA | |
built-in battery capacity | ● |
| 140mAh (3.7V Polymer battery) | |
environmental Performance | operating temperature range | ● |
| -20 ℃ - 70 ℃ |
storage Temperature range | ● |
| -30 ℃ - 80 ℃ | |
work humidity range | ● |
| 5% - 95% | |
the communication characteristics | communication Module brand/chip model | ● |
| MT6261D |
the communication band | ● |
| support 2G:850mm/900mm/1800mm/1900MHZ | |
the SIM CARD | ● |
| standard SIM CARD | |
the communication antenna | ● |
| the built-in antenna | |
GPS/BD positioning characteristics | positioning module Group brand/chip model | ● |
| branch of the micro-AT6558D |
cold startup time | ● |
| the average 32 miao | |
hot start time | ● |
| the average 1 miao | |
sensitivity (tracking) | ● |
| -162DBM | |
positioning antenna | ● |
| the built-in antenna | |
external interface | speaker output interface |
| ● |
|
the microphone input interface |
| ● |
| |
input/Output (I/O) interface |
| ● | high input (ACC) | |
ADC detection input interface |
| ● |
| |
RS485 interface |
| ● |
| |
RS232 interface |
| ● |
| |
serial port |
| ● |
| |
CAN |
| ● |
| |
k-LINE |
| ● |
| |
the form factor (s) | unit size (length * width * height) | ● |
| 90mm * 52mm * 20mm |
shell material | ● |
| ABS plastic | |
IP protection class | ● |
| IP67 | |
high intensity magnetic separation |
| ● |
| |
main unit weight | ● |
| 68g | |
