产品说明书 1份 管理卡 1张
1,support 1000 ID card.
2、支持20个“315M”学习型遥控器
3、 进出门都要用门禁卡遥控开锁，支持 ID 或 EM 兼容卡远 Speed sensor, dual reading card both inside and outside .
4、 实现了门禁主机与机电灵性锁一体化。
5、 兼容所有楼宇对讲系统和门禁系统开锁信号。
6、 设有防撬报警、不按时关门报警。
7, close the door locked automatically after, locked state with a sound-and-light tip and close collision-free, noise-free, green environmental protection.
8, damaging high-proof structural design of integration, all circuit and mechanically reasonable design, easy to install, easy operation, durable.
电器性能 ：
1、 输入电压： DC 12V+20% 静态电流 <80mA 动作电流 <350mA
2、 谢频卡开锁反应时间 <0.5S 讳瞳距离 <20mm
3、 遥控器开锁反应时间 <0.3S 遥控距离 >100m
4、 开启电流 <280mA
5、 报警输出电流 <1500mA 报警准备率 : ≥99.9%
6、 工作环境温度：-40℃-70℃，温度95%
7, immunity:IEC801-5standard
8, surge:IEC801-5standard
Installation method:
Pre-holes, playing a. From about 1 m height with position, away from the edges of the door 60mm door drill PHI 28.5+0.5 lock position. b. In hole concentric inner expansion (dig) PHI 36x3.5 stair hole, insert lock mounting plate (commonly known as the third eye). Second, install lock a. key bit upward, into the lock hole, lock from the outside toward the inside, attach the lock ring, simulation into the door hole plug end through the mounting plate (three-eyed plate hole). Observe the plug tail length out, approximately 10-15mm in length if greater than 10-15 mm, should be trimmed to meet the dimensions. c. Repeat "a" will simulate the action into the final assembly. Note: If the door leaf thickness of substandard thickening method can be used to lock the installation requirements. (Minimum thickness shall be 30 mm) d. Install and tighten the consists of two M5x45 screws (which can simulate the contrast in length after cutting, threading them into the lock hole depth 8-14 mm). e. Tighten the three eye-plate and lock with screw connection on the door, and then tighten the three corners of the eyes on the Board of four wood screws, screws when loading pay attention to frequently turn the key by hand, make plug turns freely and with the big three-eyed hole concentric. Third, loading the master lock (lock in the unlocked state) a. Open the rear cover (screw the bolt face). b． And unlock the power supply cable inlet hole (φ 10 holes at upper right) is about 100mm. c． Lock alignment. Connect the lock shaft as shown in chart position, align the lock plug, suitable for inserting. d. Master lock 4 fastening screws from the screw, one side screwing in try turning the key, the key premise of rotating flexible screw. e． Try keys unlock the bolt will stretch flexible (bolt at any position, a key to insert the lock Keyhole, normal pull and rotational flexibility was reset). IV power cord circuit board plug the tip into the power and unlock cable to complete the wiring. Five, locking lid a. Tilt and lock the cover slightly, positioning tab on the lid into the lock grooves of knob 5x5 a square shaft is suitable into hinge holes, adjusted built parallel to the fitted covers fixed-FFFFFF;text-indent:0px;color:#404040; " >
